Professional packaging testing instrument manufactured by KHT Instrument. Precision-engineered for quality control laboratories and production environments.
The HYL-1001 Tap Density / Angle of Repose Tester from KHT Instrument is engineered for reliable and repeatable testing of packaging materials. Featuring a 7-inch touchscreen controller and high-precision sensors, it delivers accurate measurements for quality assurance laboratories and production environments.
This instrument supports multiple test modes and complies with relevant ASTM, ISO, and Chinese national standards. The microcomputer-controlled stepper motor drive system ensures smooth operation with speeds adjustable from 0.1 to 500 mm/min, providing flexibility for different test requirements.
Built with a robust ball-screw mechanism and dual linear bearing guides, the HYL-1001 offers excellent mechanical stability and long service life. Standard accessories include test fixtures, a thermal printer for on-site reporting, and optional PC software for advanced data analysis.
| Parameter | Value |
|---|---|
| Sample Weight | ≤500.00 g |
| Sample Volume | ≤250.00 ml |
| Tap Count | 0 - 99,999 taps (settable; 0 = bulk density) |
| Counting Method | Photoelectric induction |
| Motor Torque | 0.86 N·m |
| Output | Built-in thermal printer |
| Tap Frequency | 0 - 300 rpm (continuously adjustable) |
| Tap Amplitude | Max 15 mm; 1 - 15 mm integer adjustable |
| Repeatability Error | ≤1% |
| Accuracy Error | ≤1% |
| Power Input | AC 220V (50/60Hz), 40W |
| Standards | GB/T 5162-2006 / ISO 3953:1993, USP |
