Professional packaging testing instrument manufactured by KHT Instrument. Precision-engineered for quality control laboratories and production environments.
The MXD-02A Coefficient of Friction Tester from KHT Instrument is engineered for reliable and repeatable testing of packaging materials. Featuring a 7-inch touchscreen controller and high-precision sensors, it delivers accurate measurements for quality assurance laboratories and production environments.
This instrument supports multiple test modes and complies with relevant ASTM, ISO, and Chinese national standards. The microcomputer-controlled stepper motor drive system ensures smooth operation with speeds adjustable from 0.1 to 500 mm/min, providing flexibility for different test requirements.
Built with a robust ball-screw mechanism and dual linear bearing guides, the MXD-02A offers excellent mechanical stability and long service life. Standard accessories include test fixtures, a thermal printer for on-site reporting, and optional PC software for advanced data analysis.
| Parameter | Value |
|---|---|
| Force Range | 0 - 5N / 0 - 10N (optional) |
| Force Accuracy | ±0.5% |
| Force Resolution | 0.001N |
| Test Speed | 100 mm/min (per GB/T 10006-1988) |
| Slider Weight | 200g (standard); 1000g, 1500g optional |
| Sample Size | 63 × 63 mm (slider); 80 × 200 mm (test plane) |
| Standards | ASTM D1894, ISO 8295, GB/T 10006, TAPPI T549, JIS K7125 |
| Display | Industrial-grade color touchscreen |
| Power Supply | AC 220V 50Hz |
| Dimensions | 525(L) × 290(W) × 280(H) mm |
| Net Weight | Approx. 25 kg |
