Professional packaging testing instrument manufactured by KHT Instrument. Precision-engineered for quality control laboratories and production environments.
The CZD-100A Ampoule Roundness Tester from KHT Instrument is engineered for reliable and repeatable testing of packaging materials. Featuring a 7-inch touchscreen controller and high-precision sensors, it delivers accurate measurements for quality assurance laboratories and production environments.
This instrument supports multiple test modes and complies with relevant ASTM, ISO, and Chinese national standards. The microcomputer-controlled stepper motor drive system ensures smooth operation with speeds adjustable from 0.1 to 500 mm/min, providing flexibility for different test requirements.
Built with a robust ball-screw mechanism and dual linear bearing guides, the CZD-100A offers excellent mechanical stability and long service life. Standard accessories include test fixtures, a thermal printer for on-site reporting, and optional PC software for advanced data analysis.
| Parameter | Value |
|---|---|
| Model | CZD-100 |
| Clamping Diameter | Forward jaw 3-55 mm, Reverse jaw 55-145 mm (other diameterscustomizable) |
| Gauge Range | 0-12.7 mm |
| Gauge Resolution | 0.001 mm |
| Gauge Mount | magnetic base, universal stand |
| Measurement Error | ≤5 filament wire |
| Test Height | 320 mm (other heightscustomizable) |
| Dimensions | 330 mm × 240 mm × 240 mm |
| Net Weight | 29kg |
| Reference Standards | YBB00052005, YBB00042005, YBB00332004, YBB00242004, YBB00402003, QB2357, QB/T1868, etc |
